FROG 500

Unique in its kind, the FROG 500 is a lift designed for the maintenance of ride-on lawnmowers, as well as 4-wheel vehicles such as quads and ATVs. It features two elevating and tilting platforms that can rise up to 100 cm at the front and 155 cm at the rear. This exclusive design allows easier access to the underside of the vehicle, making servicing safer, more comfortable and more efficient.

Available Versions:

  • F500-002 Air pump
  • F500-003 Electro-hydraulic pump
  • F500-004/R Electro-hydraulic pump with remote control

Specifications:

  • Capacity: 500 kg
  • Max height, horizontal position: 80 cm
  • Minimum height: 20 cm
  • Max height, front: 100 cm
  • Max height, rear: 155 cm
  • Wheel stops: 2
  • Safe positions: 3
  • Max track distance, external: 130 cm
  • Min track distance, external: 101 cm
  • Track size: 200 x 26 cm
  • Max track distance, internal: 74 cm
  • Min track distance, internal: 48 cm
  • Ramp dimensions: 82 x 24 cm
  • Overall dimensions of the lift: 200 x 130 cm
  • Weight: 285 kg

Electro-Hydraulic Power Unit:

  • Power: 1.1 kW
  • Europe: 230 Volts
  • Japan: 200 Volts
  • America: 110 Volts

Air Pump:

  • Air pressure: 7-10 Bar
  • Air consumption: 300L/Min

Standard Equipment:

  • Ramps: 2
  • Standard packaging: 300 kg wooden crate
  • Wheel stops: 4

Delivery: Sportsbike gives you access to over 40,000 motorcycle parts from leading brands in Australia and Europe. We source these lifting benches from BIKE LIFT in Italy and ship them to Australia via sea freight. Shipping time is typically 6-8 weeks.

Need it quickly? Contact us before ordering and we'll confirm availability and lead time: info@sportsbike.com.au

SKU F500
Brand Bike Lift
